Digga PD6-5 Auger Drive Packages for Skid Steer Loaders with a flow of 70 to 115 Lpm - 75mm Square Hub
Digga PD6-5 Auger Drive Packages for Skid Steer Loaders with a flow of 70 to 115 Lpm - 75mm Square Hub
Digga's PD5 to PD10HF range of earth drills are ideally suited for Backhoes and Excavators with a flow between 55 to 200 lpm. Innovative design allows the gearbox to go down the hole to maximise drilling depth without extentions, eliminating downtime and minimises maintenance, optimising your returns. Digga planetary auger drives are fitted with Digga/Danfoss bell motors specially designed for drilling and augering in most ground conditions.
- Compact high torque Digga manufactured gearbox
- Highly efficient design with less moving parts
- Fitted with a DIGGA Bell Motor by Danfoss
- No case drain required on excavators
- Full range of shafts available upon request
- Extreme duty shaft locking system
- Low maintenance with 5yr gear box and 3yr motor warranty
Please Advise your machines Make, Model & Pickup Specifications in special instructions during checkout.
Features & Benefits
Digga drives come packed with really practical features like top mounted hose ports, cutting edge design, and a 2 piece shaft just to name a few. Hover your mouse over the features´ 'plus' symbol on the diagram below to reveal the respective benefits.
Premium Drive Specifications
| Specification | pd5 | pd6 | pd7 | pd6hf | pd8hf | pd10hf |
|---|---|---|---|---|---|---|
| Rec Flow Range | 60-95 lpm | 70-115 lpm | 75-115 lpm | 60-150 lpm | 80-200 lpm | 100-200 lpm |
| Nominal Torque | 5151 Nm | 5596 Nm | 6040 Nm | 5634 Nm | 7136 Nm | 9690 Nm |
| Motor | 2K Geroler | 2K Geroler | 2K Geroler | 6K Geroler | 6K Geroler | 6K Geroler |
| Pressure Valve Fitted | Optional | Optional | Optional | Included | Included | Included |
| Energy Control Valve | N / A | N / A | N / A | Optional | Optional | Optional |
| Case Drain Required | Case drain recommended for backhoe loaders. Not required for excavators. |
|||||
| Max Pressure - Do not exceed |
240 bar @ 60 lpm | 240 bar @ 130 lpm | ||||
| Max Flow - Do not exceed |
115 lpm @ 130 bar | 210 lpm @ 145 bar |
230 lpm @ 130 bar |
230 lpm @ 130 bar |
||
| Max Power - Do not exceed |
25 Kw (34 hp) | 50 Kw (67 hp) | ||||
| Overall Length | 579 mm | 730 mm | 734 mm | 950 mm | 950 mm | 950 mm |
| Diameter | 240 mm | 240 mm | 240 mm | 290 mm | 290 mm | 290 mm |
| Weight (no frame / hitch) | 67 Kg | 89 Kg | 90 Kg | 149 Kg | 149 Kg | 149 Kg |
| Std Output Shaft | 75 mm Square | 75 mm Square | 75 mm Square | 75 mm Square | 75 mm Square | 75 mm Square |
| Swing Control | Optional | Optional | Optional | Optional | Optional | Optional |
| Diggalign | Optional | Optional | Optional | Optional | Optional | Optional |
| Halo | Optional | Optional | Optional | Optional | Optional | Optional |
| Rec Auger | 6 Series | 6 Series | 6 Series | 6 Series | 6 Series | 8 Series |
| Max Auger Dia Clay / Shale | 900 mm | 900 mm | 900 mm | 900 mm | 1000 mm | 1000 mm |
| Max Auger Dia Earth | 1000 mm | 1000 mm | 1000 mm | 1200 mm | 1200 mm | 1500 mm |
(*) Max/min drilling diameter (DIA) dependant on ground conditions. Guide is a recommendation only.
Due to the dimensions of this item, all deliveries will be shipped to the closest freight depot, or Commercial business with forklift facilities. Please note, that any location with a house is considered a residential property, including farms and businesses
Images and pictures may not be to scale, or the exact image of the item supplied
