Digga PD18-5 High Flow Auger Drive Packages 15 to 18 Ton - 75mm Square

Excavator Auger Drive to suit 10T-20T

Digga's PD12 to PD25 range of drilling auger drives are ideally suited for 10 to 20t excavators with a flow between 120 to 230 lpm. Fitted with Digga/Danfoss bell motors with integrated pressure relief valve and input housing. An innovative design allows the gearbox to go down the hole to maximise drilling depth without extentions, eliminating downtime and minimises maintenance, optimising your returns. Digga planetary auger drilling drives are specially designed for drilling and augering in most ground conditions.

• Compact high torque Digga manufactured gearbox
• Highly efficient design with less moving parts
• Fitted with a DIGGA Bell Motor by Danfoss
• No case drain required
• Full range of shafts available upon request
• Extreme duty shaft locking system
• Drive fits down the hole for greater digging depth
• Low maintenance with 5yr gear box and 3yr motor warranty

2 SPEED DRIVE COMES FITTED WITH 3MTR POWER LEAD AND 2 PIN CONNECTOR. 2 SPEED CONTROLLER SOLD SEPARATELY

HALO COMES WITH A 3M EXTENSION CABLE AND INCAB CIGARETTE LIGHTER PLUG - ADDITIONAL EXTENSION WILL BE REQUIRED.

Features & Benefits

Digga drives come packed with really practical features like cutting edge design and a 2 piece shaft. Hover your mouse over the features´ 'plus' symbol on the diagram below to reveal the respective benefits.

Premium Drive Specifications

SPECIFICATION	PD12	PD15	PD18	PD22	PD25
Rec Flow Range	120-230 lpm	120-230 lpm	120-230 lpm	120-230 lpm	120-230 lpm
Max Torque	11268 Nm	13897 Nm	17603 Nm	22142 Nm	26267 Nm
Motor	6K Geroler	6K Geroler	6K Geroler	6K Geroler	6K Geroler
Pressure Valve Fitted	Included	Included	Included	Included	Included
Energy Control Valve	Optional	Optional	Optional	Optional	Optional
Case Drain Required	No	No	No	No	No
Max Pressure - Do not exceed	- - - - - - - - - - 240 bar @ 130 lpm - - - - - - - - - -
Max Flow - Do not exceed	- - - - - - - - - - 230 lpm @ 130 bar - - - - - - - - - -
Max Power - Do not exceed	- - - - - - - - - - 50 Kw (67 hp) - - - - - - - - - - -
Overall Length	950 mm	1006 mm	1006 mm	1006 mm	1152 mm
Diameter	290 mm	290 mm	290 mm	290 mm	355 mm
Weight (no frame / hitch)	149 Kg	176 Kg	176 Kg	176 Kg	300 Kg
Std Output Shaft	75 mm Square	75 mm Square	75 mm Square	75 mm Square	100 mm Square
Swing Control	Optional	Optional	Optional	Optional	Optional
Diggalign	Optional	Optional	Optional	Optional	Optional
Halo	Optional	Optional	Optional	Optional	Optional
Rec Auger	8 Series	8 Series	8 Series	8 Series	10 / 11 Series
Max Auger Dia Clay / Shale	1200 mm	1200 mm	1500 mm	1500 mm	1500 mm
Max Auger Dia Earth	1600 mm	1600 mm	1600 mm	1600 mm	1600 mm

(*) Max/min drilling diameter (DIA) dependant on ground conditions. Guide is a recommendation only.

Hoses & couplers in package are as set out below:
3.0M - 3/4" HOSE, 3/4” BSP - 5/8” COUPLING - ISO COUPLERS

Please contact us for pricing for other options on hoses & couplings as set out below:
Flush Face Couplers
4.5M - 3/4" HOSE, 3/4” BSP - 5/8” COUPLING - ISO or Flush Faced coupler options available.

Please note: quick connects to your machine are not included.

Due to the dimensions of this item, all deliveries will be shipped to the closest freight depot, or Commercial business with forklift facilities. Please note, that any location with a house is considered a residential property, including farms and businesses

Please contact us for a quote for business to business or home delivery 1300 020 317 or sales@emed1.com.au

Please Advise your machines Make, Model & Pickup Specifications in special instructions during checkout.
