Couplings x 2 1/2” BSP - 1/2” COUPLING FLUSH FACE

Couplings x 2 1/2” BSP - 1/2” COUPLING FLUSH FACE

HOW TO MEASURE COUPLINGS
1. IDENTIFY TYPE OF COUPLING - FLAT FACE OR POPPET STYLE
2. MEASURE DIAMETER OF MALE COUPLING ON YOUR MACHINE

THREADED FITTINGS WHEN REPLACING COUPLINGS ON YOUR MACHINE:
1. IDENTIFY TYPE OF COUPLING - FLAT FACE OR POPPET STYLE
2. MEASURE EXTERNAL DIAMETER OF MALE COUPLING ON MACHINE
3. MEASURE INTERNAL DIAMETER OF THREADED SIDE (FEMALE BSP)

NOTE: FRACTIONAL BODY COUPLING SIZES ARE INDUSTRY STANDARDS, AND ARE NOT TO BE USED AS ACTUAL COUPLING MEASUREMENTS.
EXAMPLE: A 3/8” MALE POPPET COUPLING MEASURES 17MM (SEE DIAGRAM) - NOT 9.5MM AS THE FRACTION WOULD INDICATE.
